Nuevo SDR: ANAN-100B

The ANAN-100B (Base Model) provides an entry level 100W rig for SDR enthusiasts, receive and transmit performance levels achieved are best in class,

Differences with the ANAN-100:

- Supports Dual receivers on a single ADC

- ADC Rx input is broadband

- Uses Hermes onboard SMPS

- 1 Year Warranty against manufacturing defects

The ANAN-100B is compatible with PowerSDR, cuSDR and other PC applications that the ANAN series uses, PureSignal can be used with the ANAN-100B.

Specifications:

· Rugged Extruded Aluminum Housing, Weight: 4.5Kgs approx, Dimensions: 265.5mm (W) x 220mm (D) x 80mm (H)

· RD100HHF1 Mosfet 100W Linear amplifier (160M-6M)

· All cables, Hardware and instructions to make a complete transceiver with Hermes

· Continuous, uninterrupted, receive coverage from 10KHz to 55MHz. .

· Supports Real-Time display of entire spectrum from 0-55mHz (with suitable PC software)

· Supports 2 fully independent receivers (sharing the same antenna - and with suitable PC software)

· Each receiver can display 48/96/192/384/1152kHz of spectrum

· Blocking Dynamic Range (ARRL Method) no detectable gain compression
below ADC overload

· Transmit and receiver image rejection > 90dB

· Transmitter two-tone 3rd order IMD of -31dBc on 20m @ 100W PEP output

· 100W RF output on 160 – 6m amateur bands

· Built-in high performance preamp, with a noise floor typically -135dBm in a 500Hz Bandwidth

· Software-selectable 31dB input attenuator in 1dB steps

· High performance receiver – same specifications as the HPSDR Mercury receiver (ie Dynamic Range typically 125dB)

· FPGA code can be updated via the Industry Standard TCP/IP network Ethernet connection

· Seven user-configurable open-collector outputs, independently selectable per band and Tx/Rx (for relay control, etc - with

sequencing via PC code)

· Separate open-collector PTT connection for amplifier control, etc, with sequencer

· Microphone PTT jumper-selectable from tip or ring connection

· Bias for electret microphones via jumper

· Four user-configurable 12 bit analogue inputs (for ALC, SWR etc)

· Three user-configurable digital inputs (for linear amplifier over temperature, etc)

· I2C bus connector for control of external equipment

· Full QSK operation (performance dependant on associated PC and control software)

· Low-level transmitter output for transverter use via user-selectable output attenuator

· Stereo audio outputs at line and headphone levels

· In-built 1W stereo audio amplifier for directly driving speakers

· Direct, de-bounced connections for a Morse key (straight or iambic) and PTT

· Low phase noise (-137dBc/Hz @ 1kHz) 122.88MHz master clock, which can be phase-locked to an internal 10MHz TCXO or

external fequency reference

· Industry Standard TCP/IP network Ethernet interface supports static, APIPA or DHCP IP address

Hermes responds to ping and ARP requests and auto senses network connection speed

Eight ( Layer PCB design for the most professional, state-of-the-art, design available.
